Application of TOKY-PMS2.0 Power Monitoring System in Guangdong Rehabilitation Center for Disabled Children

Add Date: 2018-11-20    Views: 9018

Project Location: Guangdong. Guangzhou
Implementation time: October 2017

Project Description:
    The Guangdong Rehabilitation Center for the Disabled is a rehabilitation institution for the disabled. It was established on August 5, 1986. It is responsible for rehabilitation education for the disabled, education and training of rehabilitation technical personnel, community rehabilitation guidance, rehabilitation science and technology research and disability prevention. The comprehensive rehabilitation institution is the province's rehabilitation education technology resource center, and is also the demonstration window for the rehabilitation work of disabled people in the province.
    There are a hearing and speech rehabilitation institutions for deaf children, rehabilitation education for hearing-impaired children, rehabilitation education for children with intellectual disabilities, rehabilitation education for children with autism, rehabilitation training for children with cerebral palsy, hearing diagnosis, hearing aid fitting service, cochlear surgery service and disability prevention. Disability assessment and adult rehabilitation services are equal to one body. Among them, the rehabilitation technology and level of deaf children have been located in the forefront of the country, and they have been designated as the teaching base of Beijing Hearing and Speech Rehabilitation Technology College, the National Regional Center for Hearing and Speech Rehabilitation, and the postgraduate teaching and experimental base of preschool education and special education college of East China Normal University. Rehabilitation base after cochlear surgery.

Guangdong Disabled Rehabilitation Base

Scene photo 1

Scene photo 2

System implemented functions:
    The project undertakes the power monitoring of the low-voltage part of its 0.4KV power distribution station, and monitors the electrical equipment such as the incoming line cabinet, the outlet cabinet and the generator complete set of cabinets, and installs multi-function power meters. Through the TOKYPMS2.0 power monitoring system, real-time monitoring of the current, voltage, power, switch state and other electrical parameters of each circuit in the substation, thereby achieving intelligent management of the substation with few people on duty or unattended. It integrates rich functions of data acquisition, storage, graphics generation, report output, remote monitoring, etc., and carefully designed a human-machine interface.

1. Distribution network topology diagram: It can visually display the distribution of distribution lines in the form of distribution secondary trunk diagrams, and at the same time, the electrical parameters of each loop collected in real time, and the switching status of the distribution loop switches, Real-time display in the system interface;
2. Power report query: The system has the function of counting and counting the periodic meter reading of each loop. The user can freely query the power consumption of each power distribution node in any time period since the normal operation of the system;
3. Load trend curve: The load trend curve is designed for the total incoming line and the important load. It is convenient for the distribution maintenance personnel to keep abreast of the power demand and the power system load ratio, ensure the reliability of the power supply, and provide data reference for the user's energy consumption;
4. Remote signal and telemetry real-time alarm: The alarm type includes the measured value (such as current and power), the circuit breaker opening and closing, and the equipment communication fault. When the system alarms, the information voice prompt can be made, and the alarm screen is automatically popped up;
5. User rights management: User rights management function is set. Prevent unauthorized operations through user rights management
6. Communication status diagram: It can display the whole system network structure completely, and can diagnose the network communication status of the system online. When a network failure occurs, the fault unit and fault location can be automatically displayed on the screen.

System software screenshot 1

System software screenshot 2
